Wire rope sling loop with galvanized thimble on both ends compressed

20104Wire Rope, Chain & Rigging

Wire rope slings by Jakob Rope Systems, steel. 136 sizes, article no. 20104-0600-010 to 20104-3800-060.

Price on request

Rated ropes, chains and slings with documented working loads
Terminations and accessories matched to the rope
Rigging and lifting design by 828 engineers
Inspection, load testing and certification available

Ask an Engineer

Brand	Jakob Rope Systems
Product no.	20104
Category	Wire Rope, Chain & Rigging
Product family	Wire rope slings
Material	Steel
Surface	galvanized
Sizes available	136 article numbers
Manufacturer origin	Switzerland · production in Vietnam
Certification	Supplied with manufacturer certification — see spec sheet for the applicable standard
Supplied in PH by	828 Cable System Inc.
Installation	Available — see Overhead, Gantry & Jib Cranes

CertifiedManufacturer certificates with every order

InstalledBy 828-trained technicians

InspectedAnnual inspection programmes

Product no. 20104

Article Numbers.

Quote the article number for the exact size. Dimensions in mm, loads in kN, weights in kg, as labelled on the manufacturer’s technical drawing.

No.	ø	L	WLL kN	kg	Standard and Classification	Nominal strength (Mat. strength)
20104-0600-010	6	1	3.92	0.1740	EN 13414-1	1960 N/mm2
20104-0600-015	6	1.5	3.92	0.2390	EN 13414-1	1960 N/mm2
20104-0600-020	6	2	3.92	0.3040	EN 13414-1	1960 N/mm2
20104-0600-025	6	2.5	3.92	0.3690	EN 13414-1	1960 N/mm2
20104-0600-030	6	3	3.92	0.4340	EN 13414-1	1960 N/mm2
20104-0600-035	6	3.5	3.92	0.4990	EN 13414-1	1960 N/mm2
20104-0600-040	6	4	3.92	0.5640	EN 13414-1	1960 N/mm2
20104-0600-050	6	5	3.92	0.6940	EN 13414-1	1960 N/mm2
20104-0600-060	6	6	3.92	0.8240	EN 13414-1	1960 N/mm2
20104-0700-010	7	1	4.9	0.2230	EN 13414-1	1960 N/mm2
20104-0700-025	7	2.5	4.9	0.4630	EN 13414-1	1960 N/mm2
20104-0700-040	7	4	4.9	0.7030	EN 13414-1	1960 N/mm2
20104-0800-010	8	1	6.86	0.3210	EN 13414-1	1960 N/mm2
20104-0800-015	8	1.5	6.86	0.4310	EN 13414-1	1960 N/mm2
20104-0800-020	8	2	6.86	0.5410	EN 13414-1	1960 N/mm2
20104-0800-025	8	2.5	6.86	0.6510	EN 13414-1	1960 N/mm2
20104-0800-030	8	3	6.86	0.7610	EN 13414-1	1960 N/mm2
20104-0800-035	8	3.5	6.86	0.8710	EN 13414-1	1960 N/mm2
20104-0800-040	8	4	6.86	0.9810	EN 13414-1	1960 N/mm2
20104-0800-050	8	5	6.86	1.2010	EN 13414-1	1960 N/mm2
20104-0800-060	8	6	6.86	1.4210	EN 13414-1	1960 N/mm2
20104-0900-015	9	1.5	8.33	0.5450	EN 13414-1	1960 N/mm2
20104-0900-020	9	2	8.33	0.6800	EN 13414-1	1960 N/mm2
20104-0900-025	9	2.5	8.33	0.8150	EN 13414-1	1960 N/mm2
20104-0900-030	9	3	8.33	0.9500	EN 13414-1	1960 N/mm2
20104-0900-035	9	3.5	8.33	1.0850	EN 13414-1	1960 N/mm2
20104-0900-040	9	4	8.33	1.2200	EN 13414-1	1960 N/mm2
20104-0900-050	9	5	8.33	1.4900	EN 13414-1	1960 N/mm2
20104-1000-010	10	1	10.29	0.4980	EN 13414-1	1960 N/mm2
20104-1000-015	10	1.5	10.29	0.6580	EN 13414-1	1960 N/mm2
20104-1000-020	10	2	10.29	0.8180	EN 13414-1	1960 N/mm2
20104-1000-025	10	2.5	10.29	0.9780	EN 13414-1	1960 N/mm2
20104-1000-030	10	3	10.29	1.1380	EN 13414-1	1960 N/mm2
20104-1000-035	10	3.5	10.29	1.2980	EN 13414-1	1960 N/mm2
20104-1000-040	10	4	10.29	1.4580	EN 13414-1	1960 N/mm2
20104-1000-050	10	5	10.29	1.7780	EN 13414-1	1960 N/mm2
20104-1000-060	10	6	10.29	2.0980	EN 13414-1	1960 N/mm2
20104-1100-010	11	1	12.75	0.7230	EN 13414-1	1960 N/mm2
20104-1100-015	11	1.5	12.75	0.9430	EN 13414-1	1960 N/mm2
20104-1100-020	11	2	12.75	1.1630	EN 13414-1	1960 N/mm2
20104-1200-010	12	1	15.2	0.9140	EN 13414-1	1960 N/mm2
20104-1200-015	12	1.5	15.2	1.1840	EN 13414-1	1960 N/mm2
20104-1200-020	12	2	15.2	1.4540	EN 13414-1	1960 N/mm2
20104-1200-025	12	2.5	15.2	1.7240	EN 13414-1	1960 N/mm2
20104-1200-030	12	3	15.2	1.9940	EN 13414-1	1960 N/mm2
20104-1200-035	12	3.5	15.2	2.2640	EN 13414-1	1960 N/mm2
20104-1200-040	12	4	15.2	2.5340	EN 13414-1	1960 N/mm2
20104-1200-050	12	5	15.2	3.0740	EN 13414-1	1960 N/mm2
20104-1300-010	13	1	17.65	1.1140	EN 13414-1	1960 N/mm2
20104-1300-015	13	1.5	17.65	1.4340	EN 13414-1	1960 N/mm2
20104-1300-020	13	2	17.65	1.7540	EN 13414-1	1960 N/mm2
20104-1300-025	13	2.5	17.65	2.0740	EN 13414-1	1960 N/mm2
20104-1300-030	13	3	17.65	2.3940	EN 13414-1	1960 N/mm2
20104-1300-040	13	4	17.65	3.0340	EN 13414-1	1960 N/mm2
20104-1300-050	13	5	17.65	3.6740	EN 13414-1	1960 N/mm2
20104-1300-060	13	6	17.65	4.3140	EN 13414-1	1960 N/mm2
20104-1400-010	14	1	20.78	1.3260	EN 13414-1	1960 N/mm2
20104-1400-015	14	1.5	20.78	1.6960	EN 13414-1	1960 N/mm2
20104-1400-020	14	2	20.78	2.0660	EN 13414-1	1960 N/mm2
20104-1400-025	14	2.5	20.78	2.4360	EN 13414-1	1960 N/mm2
20104-1400-030	14	3	20.78	2.8060	EN 13414-1	1960 N/mm2
20104-1400-035	14	3.5	20.78	3.1760	EN 13414-1	1960 N/mm2
20104-1400-040	14	5	20.78	3.5460	EN 13414-1	1960 N/mm2
20104-1400-060	14	6	20.78	5.0260	EN 13414-1	1960 N/mm2
20104-1600-010	16	1	26.47	1.8620	EN 13414-1	1960 N/mm2
20104-1600-015	16	1.5	26.47	2.3470	EN 13414-1	1960 N/mm2
20104-1600-020	16	2	26.47	2.8320	EN 13414-1	1960 N/mm2
20104-1600-025	16	2.5	26.47	3.3170	EN 13414-1	1960 N/mm2
20104-1600-030	16	3	26.47	3.8020	EN 13414-1	1960 N/mm2
20104-1600-035	16	3.5	26.47	4.2870	EN 13414-1	1960 N/mm2
20104-1600-040	16	4	26.47	4.7720	EN 13414-1	1960 N/mm2
20104-1600-050	16	5	26.47	5.7420	EN 13414-1	1960 N/mm2
20104-1600-060	16	6	26.47	6.7120	EN 13414-1	1960 N/mm2
20104-1800-010	18	1	33.33	2.4900	EN 13414-1	1960 N/mm2
20104-1800-015	18	1.5	33.33	3.1050	EN 13414-1	1960 N/mm2
20104-1800-020	18	2	33.33	3.7200	EN 13414-1	1960 N/mm2
20104-1800-025	18	2.5	33.33	4.3350	EN 13414-1	1960 N/mm2
20104-1800-030	18	3	33.33	4.9500	EN 13414-1	1960 N/mm2
20104-1800-040	18	4	33.33	6.1800	EN 13414-1	1960 N/mm2
20104-1800-050	18	5	33.33	7.4100	EN 13414-1	1960 N/mm2
20104-2000-010	20	1	42.65	3.2410	EN 13414-1	1960 N/mm2
20104-2000-015	20	1.5	42.65	4.0010	EN 13414-1	1960 N/mm2
20104-2000-020	20	2	42.65	4.7610	EN 13414-1	1960 N/mm2
20104-2000-025	20	2.5	42.65	5.5210	EN 13414-1	1960 N/mm2
20104-2000-030	20	3	42.65	6.2810	EN 13414-1	1960 N/mm2
20104-2000-035	20	3.5	42.65	7.0410	EN 13414-1	1960 N/mm2
20104-2000-040	20	4	42.65	7.8010	EN 13414-1	1960 N/mm2
20104-2000-050	20	5	42.65	9.3210	EN 13414-1	1960 N/mm2
20104-2000-060	20	6	42.65	10.8410	EN 13414-1	1960 N/mm2
20104-2200-010	22	1	50.98	4.1510	EN 13414-1	1960 N/mm2
20104-2200-015	22	1.5	50.98	5.0710	EN 13414-1	1960 N/mm2
20104-2200-020	22	2	50.98	5.9910	EN 13414-1	1960 N/mm2
20104-2200-025	22	2.5	50.98	6.9110	EN 13414-1	1960 N/mm2
20104-2200-030	22	3	50.98	7.8310	EN 13414-1	1960 N/mm2
20104-2200-040	22	4	50.98	9.6710	EN 13414-1	1960 N/mm2
20104-2200-050	22	5	50.98	11.5110	EN 13414-1	1960 N/mm2
20104-2200-060	22	6	50.98	13.3510	EN 13414-1	1960 N/mm2
20104-2400-010	24	1	61.77	5.2210	EN 13414-1	1960 N/mm2
20104-2400-015	24	1.5	61.77	6.3160	EN 13414-1	1960 N/mm2
20104-2400-020	24	2	61.77	7.4110	EN 13414-1	1960 N/mm2
20104-2400-025	24	2.5	61.77	8.5060	EN 13414-1	1960 N/mm2
20104-2400-030	24	3	61.77	9.6010	EN 13414-1	1960 N/mm2
20104-2400-040	24	4	61.77	11.7910	EN 13414-1	1960 N/mm2
20104-2600-015	26	1.5	70.59	7.5300	EN 13414-1	1960 N/mm2
20104-2600-020	26	2	70.59	8.8150	EN 13414-1	1960 N/mm2
20104-2600-025	26	2.5	70.59	10.1000	EN 13414-1	1960 N/mm2
20104-2600-030	26	6	70.59	11.3850	EN 13414-1	1960 N/mm2
20104-2800-015	28	1.5	70.59	8.6210	EN 13414-1	1960 N/mm2
20104-2800-025	28	2.5	70.59	11.4110	EN 13414-1	1960 N/mm2
20104-2800-060	28	3	70.59	21.1760	EN 13414-1	1960 N/mm2
20104-3000-025	30	2.5	82.35	13.5850	EN 13414-1	1960 N/mm2
20104-3000-035	30	3.5	82.35	16.8350	EN 13414-1	1960 N/mm2
20104-3000-050	30	5	82.35	21.7100	EN 13414-1	1960 N/mm2
20104-3200-015	32	1.5	108	12.0090	EN 13414-1	1960 N/mm2
20104-3200-025	32	2.5	108	15.6590	EN 13414-1	1960 N/mm2
20104-3200-060	32	6	108	28.4340	EN 13414-1	1960 N/mm2
20104-3400-015	34	1.5	138	13.8360	in compliance with EN 13414-1
20104-3400-020	34	2	138	15.9010	in compliance with EN 13414-1
20104-3400-025	34	2.5	138	17.9660	in compliance with EN 13414-1
20104-3400-030	34	3	138	20.0310	in compliance with EN 13414-1
20104-3400-035	34	3.5	138	22.0960	in compliance with EN 13414-1
20104-3400-040	34	4	138	24.1610	in compliance with EN 13414-1
20104-3400-050	34	5	138	28.2910	in compliance with EN 13414-1
20104-3400-060	34	6	138	32.4210	in compliance with EN 13414-1
20104-3600-025	36	2.5	137	20.2440	EN 13414-1	1960 N/mm2
20104-3600-035	36	3.5	137	24.8240	EN 13414-1	1960 N/mm2
20104-3600-040	36	4	137	27.1140	EN 13414-1	1960 N/mm2
20104-3600-050	36	5	137	31.6940	EN 13414-1	1960 N/mm2
20104-3600-060	36	6	137	36.2740	EN 13414-1	1960 N/mm2
20104-3800-020	38	2	148	20.5940	EN 13414-1	1960 N/mm2
20104-3800-025	38	2.5	148	23.1240	EN 13414-1	1960 N/mm2
20104-3800-030	38	3	148	25.6540	EN 13414-1	1960 N/mm2
20104-3800-035	38	3.5	148	28.1840	EN 13414-1	1960 N/mm2
20104-3800-040	38	4	148	30.7140	EN 13414-1	1960 N/mm2
20104-3800-050	38	5	148	35.7740	EN 13414-1	1960 N/mm2
20104-3800-060	38	6	148	40.8340	EN 13414-1	1960 N/mm2

According EN 13414-1
Made of galvanized, single-layer circular wire strand rope with fiber core
Safety factor 5
Other lengths on request
Working load limit see also table comply with EN 13414-11
