Jakob Rope Systems
Rope pulley AL-A 2-roller, with plain bearing and anchorage 64 kN
Rope pulleys by Jakob Rope Systems. 1 size, article no. 01840/2/B.
Price on request
- Rated ropes, chains and slings with documented working loads
- Terminations and accessories matched to the rope
- Rigging and lifting design by 828 engineers
- Inspection, load testing and certification available
| Brand | Jakob Rope Systems |
|---|---|
| Product no. | 01840/2/B |
| Category | Wire Rope, Chain & Rigging |
| Product family | Rope pulleys |
| Sizes available | 1 article number |
| Manufacturer origin | Switzerland · production in Vietnam |
| Certification | Supplied with manufacturer certification — see spec sheet for the applicable standard |
| Supplied in PH by | 828 Cable System Inc. |
| Installation | Available — see Overhead, Gantry & Jib Cranes |
CertifiedManufacturer certificates with every order
InstalledBy 828-trained technicians
InspectedAnnual inspection programmes
Product no. 01840/2/B
Article Numbers.
Quote the article number for the exact size. Dimensions in mm, loads in kN, weights in kg, as labelled on the manufacturer’s technical drawing.
| No. | ø | WLL kN | kg |
|---|---|---|---|
| 01840/2/B | 11.2 | 64 | 8.0000 |
- Aluminium side flange, hinged
- Plastic rope pulley
- Safety 4-fold
- Rope speed: max. 10 m/min
