Safety Lifeline Cable Tester KIT 1 - Frame Only
Cable test frame and tooling for in-situ testing of swaged end fittings on 8mm wire-rope horizontal lifeline systems. Supplied without a tester; works with an existing M2000 or M35+.
Price on request
- Proves anchors and fixings in place
- Digital gauges with calibration certificates
- Adaptors for almost any fixing
- Training and on-site testing by 828
| Brand | Hydrajaws |
|---|---|
| Model / SKU | 030-006 |
| Category | Pull-out & Load Testers |
| Product family | Pull Tester Kits |
| Max tensile load | 20kN |
| Cable | 8mm wire rope |
| Compatible testers | M2000 or M35+ (not included) |
| Frame | Cable test frame with extension bars; single-hinge clamp with swing bolt |
| Carry case | Pockets for M35+ tester and accessories |
| Standards referenced | BS 7883 (swaged components) |
| Manufacturer origin | United Kingdom |
| Certification | Supplied with manufacturer certification — see spec sheet for the applicable standard |
| Supplied in PH by | 828 Cable System Inc. |
| Installation | Available — see Load Measurement & Pull-out Testing |
Cable test frame and tooling for in-situ testing of swaged end fittings on 8mm wire-rope horizontal lifeline systems. Supplied without a tester; works with an existing M2000 or M35+.
In the kit
- Cable test frame with extension bars
- Operating nut and drop rod for M35+
- Pulling pin for M2000
- Hydrajaws 80Nm Verify Torque
- 24mm ratchet spanner
- Ratchet wrench with 17mm socket
- 14mm spanner
- Ball driver(s)
- 8mm barrel clamp
- 12mm slotted adaptor
- Extension collar insert 12mm
- Extra extension rods
- Knurled adaptor 8mm (10mm and 12mm optional)
- 6mm hex key
- Tool lanyards
Supplied by 828
828 Cable System is the authorized Hydrajaws distributor in the Philippines. We supply the testers with their calibration certificates, can train your team to use them, and can carry out on-site pull-out testing for you.
