Jakob Rope Systems
Habegger HIT-TRAC 16B gasoline motorized rope hoist
Motorized rope hoist HIT-TRAC 16 by Jakob Rope Systems. 1 size, article no. 07016/11.
Price on request
- For controlled lifting, pulling and load monitoring
- Selected to your loads and duty
- Installation and integration by 828
- Inspection, load testing and certification available
| Brand | Jakob Rope Systems |
|---|---|
| Product no. | 07016/11 |
| Category | Lifting & Load Measurement |
| Product family | Motorized rope hoist HIT-TRAC 16 |
| Sizes available | 1 article number |
| Manufacturer origin | Switzerland · production in Vietnam |
| Certification | Supplied with manufacturer certification — see spec sheet for the applicable standard |
| Supplied in PH by | 828 Cable System Inc. |
| Installation | Available — see Overhead, Gantry & Jib Cranes |
CertifiedManufacturer certificates with every order
InstalledBy 828-trained technicians
InspectedAnnual inspection programmes
Product no. 07016/11
Article Numbers.
Quote the article number for the exact size. Dimensions in mm, loads in kN, weights in kg, as labelled on the manufacturer’s technical drawing.
| No. | ø | WLL kN | kg |
|---|---|---|---|
| 07016/11 | 11.2 | 16 | 44.0000 |
- With drive motor 2-stroke engine
- Power: 5.2 kW
- Rope speed: max. approx. 10 m/min
- Overload protection due to slipping clutch at approx. 20 % overload
- Rope length unlimited
- Lowering is performed manually via the lowering brake
