Jakob Rope Systems
Habegger HIT-TRAC 128E vario electric motorized rope hoist
Motorized rope hoist HIT-TRAC 128 by Jakob Rope Systems. 1 size, article no. 08401.
Price on request
- For controlled lifting, pulling and load monitoring
- Selected to your loads and duty
- Installation and integration by 828
- Inspection, load testing and certification available
| Brand | Jakob Rope Systems |
|---|---|
| Product no. | 08401 |
| Category | Lifting & Load Measurement |
| Product family | Motorized rope hoist HIT-TRAC 128 |
| Sizes available | 1 article number |
| Manufacturer origin | Switzerland · production in Vietnam |
| Certification | Supplied with manufacturer certification — see spec sheet for the applicable standard |
| Supplied in PH by | 828 Cable System Inc. |
| Installation | Available — see Overhead, Gantry & Jib Cranes |
CertifiedManufacturer certificates with every order
InstalledBy 828-trained technicians
InspectedAnnual inspection programmes
Product no. 08401
Article Numbers.
Quote the article number for the exact size. Dimensions in mm, loads in kN, weights in kg, as labelled on the manufacturer’s technical drawing.
| No. | ø | WLL kN | kg |
|---|---|---|---|
| 08401 | 28 | 128 | 870.0000 |
- Power: 7.5 kW
- Voltage: 50 Hz / 3x400 V, 15.1 A
- with engine cooler and emergency mode control
- Rope speed: 0.5 - 2.5 m/min
- Intermittent duty: 100 %
- Supply cable 5 m, Control cable 3 m
- Overload protection by current limitation at approx. 20 % overload
- Rope length unlimited
