GreenBlock 160 Set
GreenBlock by Jakob Rope Systems. 8 sizes, article no. 30805-0160-120-1 to 30805-0160-260-8.
Price on request
- Transparent, durable stainless steel mesh and frame systems
- For balustrades, enclosures, aviaries and green walls
- Layout and edge-detail design by 828
- Supply and tensioned installation by 828
| Brand | Jakob Rope Systems |
|---|---|
| Product no. | 30805-0160 |
| Category | Webnet, Frames & Green Facades |
| Product family | GreenBlock |
| Sizes available | 8 article numbers |
| Manufacturer origin | Switzerland · production in Vietnam |
| Certification | Supplied with manufacturer certification — see spec sheet for the applicable standard |
| Supplied in PH by | 828 Cable System Inc. |
| Installation | Available — see Webnet |
CertifiedManufacturer certificates with every order
InstalledBy 828-trained technicians
InspectedAnnual inspection programmes
Product no. 30805-0160
Article Numbers.
Quote the article number for the exact size. Dimensions in mm, loads in kN, weights in kg, as labelled on the manufacturer’s technical drawing.
| No. | a | b1 | b2 | b3 | ø d1 | ø d2 | ø d3 | ø d4 | kg |
|---|---|---|---|---|---|---|---|---|---|
| 30805-0160-120-1 | M12 | 120 | 100 | 112 | 160 | 125 | 92 | 210 | 2.7500 |
| 30805-0160-140-2 | M12 | 140 | 120 | 117 | 160 | 125 | 92 | 210 | 3.0600 |
| 30805-0160-160-3 | M12 | 160 | 140 | 127 | 160 | 125 | 92 | 210 | 3.3400 |
| 30805-0160-180-4 | M12 | 180 | 160 | 132 | 160 | 125 | 92 | 210 | 3.6200 |
| 30805-0160-200-5 | M12 | 200 | 180 | 137 | 160 | 125 | 92 | 210 | 3.9200 |
| 30805-0160-220-6 | M12 | 220 | 200 | 147 | 160 | 125 | 92 | 210 | 4.2200 |
| 30805-0160-240-7 | M12 | 240 | 220 | 152 | 160 | 125 | 92 | 210 | 4.5100 |
| 30805-0160-260-8 | M12 | 260 | 240 | 157 | 160 | 125 | 92 | 210 | 4.8000 |
- Consisting of base body and extension, assembling material, cover and sealing material.
- The supply does not include composite mortar and spacers.
- Suitable for spacers type GreenWebnet 30897-0100-00, 30897-0150-00, and 30897-0200-00.
- Installation requires the necessary expertise. Please refer to the additional instructions in the assembly manual.
