Jakob Rope Systems
Clamp holder for countersunk head
Clamp holders by Jakob Rope Systems, stainless steel AISI 316L (1.4404). 1 size, article no. 30833-0300-15.
Price on request
- Marine-grade stainless steel for long service life
- Complete system: rope or rod, terminals and fixings from one range
- Load and tension design by 828 rope engineers
- Supply, swaging and installation by 828
| Brand | Jakob Rope Systems |
|---|---|
| Product no. | 30833-0300-15 |
| Category | Architectural Cables & Fittings |
| Product family | Clamp holders |
| Material | Stainless steel 316L |
| Sizes available | 1 article number |
| Manufacturer origin | Switzerland · production in Vietnam |
| Certification | Supplied with manufacturer certification — see spec sheet for the applicable standard |
| Supplied in PH by | 828 Cable System Inc. |
| Installation | Available — see Architectural Ropes |
CertifiedManufacturer certificates with every order
InstalledBy 828-trained technicians
InspectedAnnual inspection programmes
Product no. 30833-0300-15
Article Numbers.
Quote the article number for the exact size. Dimensions in mm, loads in kN, weights in kg, as labelled on the manufacturer’s technical drawing.
| No. | ø | a | b | e | f | g | ø d1 | ø d2 | kg |
|---|---|---|---|---|---|---|---|---|---|
| 30833-0300-15 | 3-4 | M6 | 40 | 6 | 26 | 11 | 20 | 7.5 | 0.0480 |
- For attaching shelves and signs.
- Headless screw with nylon head for a gentle clamping of glass.
- Suitable for circular wire strand rope Ø 3 and Ø 4 mm.
- Compatible with countersunk head pressed 30866-0300 and 30666-0400.
- Compatible with countersunk head with internal thread 30866-0400-02 and 30666-0500-02.
- Compatible with countersunk head Univiss 30866-0500-11.
