Circular wire strand rope Duplex 6 x 7 + WC
Circular wire strand rope by Jakob Rope Systems, stainless steel AISI 318LN (1.4462). 2 sizes, article no. 10820-0151 to 10820-0201.
Price on request
- Marine-grade stainless steel for long service life
- Complete system: rope or rod, terminals and fixings from one range
- Load and tension design by 828 rope engineers
- Supply, swaging and installation by 828
| Brand | Jakob Rope Systems |
|---|---|
| Product no. | 10820 |
| Category | Architectural Cables & Fittings |
| Product family | Circular wire strand rope |
| Material | Duplex stainless steel |
| Standard | EN 12385/DIN 3053 |
| Nominal strength | 1570 N/mm2 |
| Sizes available | 2 article numbers |
| Manufacturer origin | Switzerland · production in Vietnam |
| Certification | Supplied with manufacturer certification — see spec sheet for the applicable standard |
| Supplied in PH by | 828 Cable System Inc. |
| Installation | Available — see Architectural Ropes |
CertifiedManufacturer certificates with every order
InstalledBy 828-trained technicians
InspectedAnnual inspection programmes
Product no. 10820
Article Numbers.
Quote the article number for the exact size. Dimensions in mm, loads in kN, weights in kg, as labelled on the manufacturer’s technical drawing.
| No. | ø | Constr | F_Rd kN ETA | MBL kN | kg |
|---|---|---|---|---|---|
| 10820-0151 | 1.5 | 6 x 7 + WC | 0.91 | 1.37 | 0.0090 |
| 10820-0201 | 2 | 6 x 7 + WC | 1.6 | 2.4 | 0.0160 |
- Duplex stainless steel, highly corrosion-resistant.
- Lacing rope for the product groups Webnet Duplex 20268 and Webnet Duplex 20269.
